Description
The Jasic MIG 270 Separate Water Cooled inverter welder is equipped with powerful IGBT components, a digital A/V display and multi process capabilities. This modular inverter package offers excellent welding characteristics and consistently reliable performance for highly demanding and repetitive weld cycles. This high quality 230V MIG welder delivers an impressive 270 amps at 30% duty cycle, making it an excellent choice for single phase applications.
- Single Phase IGBT MIG inverter welder
- High powered 230V welding machine
- Digital amp and volt meters
- 4 Roll wire feed unit
- High duty cycle – single phase inverter
- Advanced control circuitry
- Suitable for 0.6/0.8/1.0 and 1.2mm wires
- Burn back control & wire inching
- 2T/4T trigger function
- Power & status LED’s
- Gas check function
- Variable inductance
- Inverter trolley takes full size gas cylinder
Inverter Package Includes
Inverter power source, Trolley, 4 roll wire feed unit, 5 metre Interconnecting cable, MIG welding torch, Work return lead and clamp, Gas hose & regulator, Operating Instructions.
Technical Specifications
Input Voltage AC 230V – 50/60 Hz
Ieff (A) 28.9
Input Power (kVA) 12.1
Voltage Adjustment Range (V) 11 – 29
Current Range (A) 30 – 270
Duty Cycle @ 40°C 270A @ 30%
No-Load Voltage (V) 54
Wire Speed (m/min) 0 – 16
Efficiency (%) 85
Power Factor 0.75
Protection/Insulation Class IP21S/F
Dimensions (LxWxH mm) 1020 x 505 x 1460
Weight (Kg) 101
